TXOJ CAI TSHIAB | |
Yam khoom | K19H-UP1000S12F |
Output voltage | +12VDC |
Rated tam sim no | 67A |
Rated zog | 804W |
Ripple & suab nrov | 200 mV-p |
Output adjustable ntau yam | ±5% |
Cov zis raug | ±1% |
Kab kev cai | ±0.5% |
Load Regulation | ±0.5% |
Txoj Cai Hla | -- |
Teeb tsa, sawv, tuav lub sijhawm | 500ms, 30ms, 5ms / 115VAC 300ms, 30ms, 10ms / 230VAC |
NPAJSPECIFICATION | |
Rated input voltage | 90-264V AC |
Input voltage ntau | 88-264VAC |
Input Tam sim no | 10A/115V , 5A/230V |
Ntau zaus | 47-63 Hz |
efficiency | 92% @230V,89% @115V |
Fais fab xwm txheej | >0.98@110V;>0.95@220V |
Inrush tam sim no | Txias pib 40A / 230V |
Cov dej ntws tam sim no | <3.5mA@240V AC |
KEV TIV THAIV | |
Kev tiv thaiv overload | 105 ~ 135%, Hiccup tiv thaiv, tsis siv neeg rov qab |
Output luv Circuit Court tiv thaiv | Xauv tawm kev tiv thaiv, fais fab tuag ces tsis siv neeg rov qab |
Tso zis tshaj voltage tiv thaiv | 15-18V |
Tshaj kub tiv thaiv | Cov ntaub thaiv npog> 105 degree. Kaw, rov zoo li qub tom qab kub poob. |
Lwm yamFUNCTION | |
Pab txhawb zog | 12V0.3A pab voltage tso zis yog muab |
Standby muaj nuj nqi | RC davhlau ya nyob twg, nce qib siab, tua tawm cov zis |
Ib puag ncig | |
Ua haujlwm temp., humidity | -20 ~ 60 degree, 10 ~ 90% RH, Tsis muaj condensation |
Kub Coefficient | ± {{0}}.3% / degree (0 ~ 50 degree) |
Kev vibration | 10 ~ 500Hz, 2G 10min. / 1cycle, PERIOD RAU 60min. IB AXES |
● Tag nrho cov kev ntsuas yog ntsuas raws li cov kev cai ntawm 230VAC input, rated load, ambient kub 25 degree thiab av noo 70%; ● Qhov tseeb: suav nrog kev teeb tsa kev ua yuam kev, kab kev cai, kev thauj khoom, thiab lwm yam. Txoj cai kab: ntsuas nrog cov input voltage hloov ntawm qis mus rau siab nyob rau hauv rated load tej yam kev mob; Load tswj: ntsuas nrog cov zis hloov pauv los ntawm 0 load rau 100% load; Ripple test: Txuas lub hwj huam mov thiab lub load nrog 30cm-ntev twisted hlau. Qhov kawg load yog txuas nrog 0.1u thiab 47u capacitors, thiab nws yog ntsuas ntawm qhov kawg load nrog 20MHz oscilloscope; |
Lub 800W kev kho mob thiab kev zoo nkauj fais fab mov yog lub zog txhim khu kev qha thiab muaj txiaj ntsig zoo uas muab kev ua haujlwm zoo rau ntau yam kev kho mob thiab kev zoo nkauj. Nrog nws cov thev naus laus zis thiab thev naus laus zis, nws ua kom cov khoom tsim tau zoo ib yam thiab ruaj khov uas pab txhim kho cov khoom siv kho mob thiab kev zoo nkauj.
Raws li ib qho tseem ceeb ntawm cov khoom siv kho mob thiab kev zoo nkauj, cov khoom siv hluav taws xob no yog tsim los ua kom tau raws li cov qauv kev nyab xeeb thiab zoo tshaj plaws, kom ntseeg tau tias nws ib txwm muab lub zog txhim khu kev qha los txhim kho kev ua haujlwm ntawm cov khoom siv uas nws txhawb nqa. Nws cov qauv tsim ua kom ntseeg tau tias nws yooj yim rau nruab thiab siv, ua rau nws muaj kev xaiv nrov rau ob tus kws tshaj lij thiab cov neeg pib tshiab hauv kev kho mob thiab kev zoo nkauj.
