AC DC hluav taws xob muab lub zog hluav taws xob 1500W 48V, qhib qauv ncej thiab nrog kiv cua txias thiab nrog lub hau tuaj yeem muab los ntawm peb lub Hoobkas.

Nta:

1, Qhov ua haujlwm siab 1500W 48V hloov fais fab mov;

2, Ua-hauv EMI lim thiab PFC muaj nuj nqi, suab nrov tsawg, muaj kev ntseeg siab;

3, 48V 31.25A fais fab mov nrog ntau yam ntawm AC input voltage;

4, 1500W 48V fais fab mov nrog overload, luv Circuit Court, dhau voltage thiab dhau kev tiv thaiv kev kub;

Tsis
Yam TSIS tau		K50-UP1500S48
Tsim Tawm	Tsim Tawm Voltage	+48VDC
	Nyob Tam Sim No	31.25A
	Lub Hwj Chim Rated	1500W
	Ripple& Suab nrov	550mVp-p
	Tso Tawm ADJ.Range	45.6-50.4V
	Rau Cov Raug Lawm	±1%
	Kab Kev Cai	±0.5%
	Load Cov Kev Cai	±1%
	Teeb tsa, nce, Cia sijhawm	600ms, 30ms, 12ms
Cov lus qhia	Cov lus qhia Voltage Ntau Yam	100-240V AC
	Cov Tswv Yim Tam Sim No	7.4A / 230Vac, 15.5A / 115Vac
	Input Frequency	50-60Hz
	Qhov Zoo @ 230Vac	93%
	Lub Zog Khoom	PF ＞ 0.98 / 115V lossis PF ＞ 0.95 / 230V
	Inrush Tam Sim No	Txias pib 60A / 230Vac
	Nplooj Ntu Tam Sim No	0.5mA@240V
Kev Tiv Thaiv	Tshaj Load	105 ~ 150% Hiccup, rov ua haujlwm tsis siv neeg
	Luv Circuit Court	Kev tiv thaiv kaw, Rov qab mus rau qhov qub tom qab rov pib dua
	Tso Tawm Ntau Dua	＞ 120% Txhawm kaw, Kaw kev tiv thaiv, Rov qab mus rau qhov qub tom qab rov ua dua
	Nyob Dhau Temp,	TS1 txoj hauj lwm ＞ 105 ℃ nws yuav muaj kev tiv thaiv, tom qab ntawd rov ua haujlwm tsis siv neeg
Muaj nuj nqi	Ntxuam Khoom Siv	12V@0.3A rau tsav tus kiv cua, kam rau ua ± 15%, Ua nrog kiv cua yuam cua txias
Tej thaj chaw deb	Chaw taws teeb ON-OFF tswj	Fais fab tuag: luv luv zog OFF: qhib
Ib puag ncig	Ua Haujlwm Temp, Vaum	-20 ~ 70 ℃, 10 ~ 90% RH, Tsis muaj hws
	Cia Lub Sij Hawm, Vaum	-20 ~ 85 ℃, 10 ~ 95% RH
	Temp, Drift	±0.03%/℃ (0~50℃)
	Kev Co	10 ~ 500Hz, 2G 10min./1cycle, PERIOD RAU 60min. TXHUA AXES
Kev Ruaj Ntseg& EMC	Cov Qauv Kev Nyab Xeeb	GB4943 EN60950
	Nrig Voltage	Kuv / PO / P: 3KV; Kuv / P-FG: 1.8KV; O / P-FG: 0.6KV AC 1min
	Rwb thaiv tsev Kuj	I / PO / P, I / P-FG, O / P-FG: 500VDC / 100M Ohms
	EMC Cov Qauv	---
Lwm tus	MTBF	＞ 50K teev
	Qhov ntev	205 * 100 * 65mm (L * W * H)
	Nyhav	1.5KG
Sau ntawv	1. Txhua yam tsis xws luag 230VAC cov tswv yim, ntsuas cov ntsuas, ntsuas kub thaj tsam 25 ℃, ntsuas raws li 70% cov av noo; 2. Qhov Peev Xwm: suav nrog kev ua kom nkag siab, kab kev cai, thauj cov kev cai thiab lwm yam; 3. Ripple Test: 30cm ntev xa xov txuas rau lub zog txuas thiab cov load ntawm sab load thiab 0.1u thiab 47u lub zog rau 20MHz oscilloscope ntsuas ntawm qhov kawg load; 4. Kab kev cai: ntawm cov sijhawm thauj cov xwm txheej, cov hluav taws xob voltage hloov los ntawm qis rau siab ntsuas; 5.Txoj cai tswj kev thauj khoom: ntsuas cov khoom tso tawm los ntawm 0 txog 100% kev hloov khoom ntsuas ntsuas;

dc power supply 1500w

FAQ:

Q1: Koj puas muab cov qauv dawb?

A: Thov txim, feem ntau peb tsis txhob' t muab cov qauv dawb.

Q2: Koj lub sijhawm them nyiaj yog dab tsi?

A: 30% tso cia them ua ntej tsim khoom thiab 70% tshuav nyiaj them ua ntej khoom xa tuaj.

Q3: Cov qauv them twg koj tuaj yeem lees txais?

A: T / T, PayPal thiab lwm yam. Peb lees txais txhua lub sijhawm ua haujlwm yooj yim thiab nrawm.

Q4: Koj puas muab cov kev kuaj thiab kev ntsuam xyuas?

A: Yog lawm, peb tuaj yeem pab ua cov ntaub ntawv kuaj mob tsim rau khoom lag luam thiab cov ntawv tshaj tawm Hoobkas tshawb xyuas.

Cim npe nrov: 1500w fais fab mov 48v, Tuam Tshoj, tuam ntxhab, cov chaw muag khoom, lub Hoobkas, kho kom zoo, yuav, ua nyob rau hauv Suav teb
