Tus qauv ntawm K26H-U150S30 yog dc30v 5a cov zis, nws yog tsim rau tus neeg siv khoom uas tsim cov khoom siv audio, cov zis tam sim no tuaj yeem nce mus txog 7.5A, uas txhais tau tias thaum cov zis tam sim no ntau dua 7.5A, lub zog yuav tiv thaiv.

Nta:

1, 150W fais fab hluav taws xob me me ib cov khoom siv fais fab;

2, DC30V 5A SMPS muaj qhov me me, kev ua haujlwm siab;

3, Thoob ntiaj teb kev siv hluav taws xob tag nrho;

4, 150W 30V dc fais fab mov muaj built-in nquag PFC muaj nuj nqi;

5, Ua lim nrog, tsis tshua muaj suab nrov, muaj kev ntseeg siab;

6, Tshaj dhau, luv luv Circuit Court, hauv qab voltage, dhau voltage, dhau kev tiv thaiv kev kub thiab lwm yam.

Tsis
Yam TSIS tau		K26H-U150S30
Tsim Tawm	Tsim Tawm Voltage	30VDC
	Nyob Tam Sim No	5A
	Khwv Tam Sim No	0-5A
	Lub Hwj Chim Rated	150W
	Ripple& Suab nrov	240mVp-p
	Kho Cov Ncauj Lus Pom Tau Ntau Yam	±10%
	Rau Cov Raug Lawm	±1%
	Kab Kev Cai	±0.5%
	Load Cov Kev Cai	±0.5%
	Teeb tsa, nce, Cia lub sijhawm	50ms, 50ms, 20ms
Cov lus qhia	Cov lus qhia Voltage Ntau Yam	100 ~ 240V AC
	Cov Tswv Yim Tam Sim No	1A/230V, 2A/115V
	Input Frequency	50 ~ 60Hz
	Qhov Txiab	86% @ 230VAC, 83% @ 100VAC
	Lub Zog Khoom	PF ＞ 0.5 / 115V PF ＞ 0.5 / 230V
	Inrush Tam Sim No	Txias pib 30A @ 230V
	Nplooj Ntu Tam Sim No	& lt; 0.5mA@240V
Kev Tiv Thaiv	Tshaj Load Tiv Thaiv	105 ~ 150%, Hiccup kev tiv thaiv, rov ua haujlwm tsis siv neeg
	Kev Tiv Thaiv Luv luv	Hiccup, rov ua haujlwm tsis siv neeg
	Rau cov zis tawm-voltage kev tiv thaiv	36-42V Kaw kaw, Kaw kev tiv thaiv, rov qab mus rau qhov qub tom qab rov pib dua
	Kub dhau kev tiv thaiv	Aluminium plhaub temp., ＞ 105 ℃ nws yuav muaj kev tiv thaiv, tom qab ntawd rov ua haujlwm tsis siv neeg
Ib puag ncig	Ua Haujlwm Temp., Vaum	-10 ~ 50 ℃, 10 ~ 90% RH, Tsis muaj hws
	Cia Lub Sij Hawm., Vaum	-20 ~ 85 ℃, 10 ~ 95% RH
	Temp., Drift	±0.03%/℃(0~50℃)
	Kev Co	10 ~ 500Hz, 2G 10min / 1cycle, PERIOD RAU 60min Tawm Ib QA
Kev Ruaj Ntseg& EMC Cov Qauv	Cov Qauv Kev Nyab Xeeb	GB4943, EN60950
	Nrig Voltage	Kuv / PO / P: 3KV; Kuv / P-FG: 1.5KV; O / P-FG: 0.5KV AC 1min
	Rwb thaiv tsev Kuj	I / PO / P, I / P-FG, O / P-FG: 500VDC / 100M Ohms
	EMC Cov Qauv	GB9254, EN55022 HOOB B
Lwm tus	Qhov ntev	115 * 59 * 35mm (L * W * H)
	Nyhav	0.3kg
	MTBF	＞ 50K teev MIL-HDBK-217F (25 ℃)
	Ntxuam Khoom Siv	/

audio power supply 30V

FAQ:

Q1: Muaj pes tsawg hom khoom uas koj lub tuam txhab tsim?

A: Tam sim no peb muaj ntau dua 1,000 cov khoom. Peb muaj cov lag luam muaj zog ntawm OEM, tsuas yog muab peb cov khoom lag luam lossis koj lub tswv yim uas koj xav tau, peb yuav tsim khoom rau koj.

Q2: Thaum twg kuv tuaj yeem tau txais tus nqi?

A: Feem ntau peb hais tawm hauv 8 teev tom qab peb tau txais koj qhov kev nug.

Q3: Koj puas muab cov qauv dawb?

A: Thov txim, feem ntau peb tsis txhob' t muab cov qauv dawb.
