Cov Nta Tseem Ceeb:
Siab efficiency: Niaj hnub hloov fais fab cov khoom siv feem ntau muaj cov khoom siv tau ntawm 90% lossis siab dua, txo cov cua sov thiab lub zog poob.
Cog Lus Tsim: Daim ntawv me me kom haum rau hauv cov chaw nruj, feem ntau nrog lub zog hluav taws xob siab.
Dav Inf Intrast Voltage Ntau: Feem ntau txhawb ntau cov ntawm cov lus qhia voltages (piv txwv li, 90-305 v ac) rau ntiaj teb compatibility.
Nquag Pfc (Lub Zog Kev Kho Mob): Txhim kho lub zog loj thiab txo cov harteronic distortion, ua rau nws muaj zog ntau dua.
Kev Tiv Thaiv Cov Nta: Ntau dhau-voltage, dhau-tam sim no, luv-qhov kev tiv thaiv, thiab dhau kev tiv thaiv kub kom paub meej kev nyab xeeb thiab kev ntseeg tau.
Cua Txias Tshuab: Muaj peev xwm suav nrog cov kiv cua ua lossis ua haujlwm dhau los nyob ntawm qhov loj thiab lub zog yuav tsum tau ua.
Ntawv muaj: Ua raws li kev nyab xeeb thiab EMI cov qauv zoo li CE, UL, ROHS, thiab lwm yam.
Cov lus qhia rau xaiv: 1. Qhov loj txwv: Ntsuas cov chaw muaj thiab paub meej tias lub zog siv hluav taws xob. 2. Cua txias yuav tsum: txiav txim siab yog tias kiv cua txias lossis txias txias yog tsim nyog rau koj ib puag ncig. 3. Cov khoom lag luam yuav tsum tau: Ua kom cov khoom siv hluav taws xob tuaj yeem ua rau lub ncov thiab tas mus li ntawm koj daim ntawv thov. 4. Daim ntawv pov thawj: Txheeb xyuas tias lub zog hluav taws xob ua tau raws li qhov tsim nyog nyab xeeb thiab kev tswj hwm rau koj thaj av.
Cov Lus Qhia Tshwj Xeeb:
Cov Zauv Voltage: +48 Vdc
Rated tam sim no: 14.6a
Rated Hwj Chim: 700W
Ripple & nrov: 600Mvp-p
Kev Tawm Tawm Qhov Tseeb: ± 1.5%
Cov tswv yim Voltage ntau: 90V ~ 305V AC
Cov tswv yim tam sim no: 10A Max
Zaus: 50 ~ 60Hz
Kev Ua Tau Zoo:> 92% @ 230VAC
Lub Hwjchim Tsim: PF> {{{0}}}}. 98/100 / 10030V
Cov Qauv Kev Nyab Xeeb: GB4943, en 60950-1, en 62368-1
Withstand: Kuv / PO / P: 3KV; Kuv / P-FG: 1.8kv; o / p-fg: 0. 6kv ac 1min.
Rwb thaiv tsev tsis kam: Kuv / Po / P, I / P-FG, O / P-FG: 500v ohms
EMC qauv: En55015 chav kawm b, en 61000-3-2}}}, en 61000-4-5, kev ua tau cov txheej txheem c
MTBF> 50K Hrs, Mil-HDBK {2}} f (25 degree)
Qhov loj me: 155 * 60 * 40 hli (l * h * h)
Qhov hnyav: 670 g.
